BT40 MLC ER20 Synchro Tapping Chuck - 35mm
OM32385BT40 MLC
-
BT MAS403 (JIS 6339)
-
Minimum Length Compensation Tapping Chucks
-
+/-0.5mm Compression & Expansion
-
High Concentricity Enables High Speed Tapping
- Recommended for use with QCTC Type Collets
| Description | BT40 MLC ER20 |
| Capacity | M3-M16 |
|
Clamping Range (mm) |
3.5-10 |
|
Collet Nut |
ER20 |
| Form | AD/B |
|
D1 |
35mm |
| D2 | 34mm |
|
L |
85mm |
| Comp. | 0.5mm |
| Exp. | 0.5mm |
| Part Number | OM32385 |
