1.9mm Micro Drill 2 Flute Solid Carbide Through Coolant IchAda Coated 5xD - OSG

OSG-8732033

OSG

  • £116.43


ADO-MICRO-5D - 1.9mm

    The A Brand ADO-MICRO is ideal for applications in carbon steel, alloy steel, stainless steel, cast iron, ductile cast iron, aluminium alloy, titanium alloy and heat resistant alloy.

    Product features and benefits:

    • First Choice in quality and performance.
    • Oil Holes Large flow volume enables superior chip evacuation.
    • Double Margin (5xD) Supports straightness of drill direction.
    • Through Coolant/IchAda Coating Provides excellent surface smoothness.
    • Extended Flute Chips are discharged from the tip of the flute to the extended flute with enhanced evacuation capability.
    • Removed End of Margin Capability to smoothly discharge “micro sludges” that can be easily accumulated around the outer periphery of the tool, which is a key cause of abrupt tool breakage.

    Diameter (DC) 1.9mm
    Flute Length (LU) 9.5mm
    Neck Length (LCF) 19mm
    Overall Length (OAL) 65mm
    Shank Diameter (DCON) 3.0mm
    Shank Length (LS) 43.4mm
    PL 0.4mm
    Shank Tolerance Shrink Fit
